Key features for HD-MAX ECHO SOUNDER

1) Optimized sounding technology
2) Industrial high speed computer platform
3) 17″ large-size screen with adjustable display angle
4) Userfriendly surveying compatible with hypack and etc.

HD-MAX is a full-digit echo sounder for precision measurement in hydrology, reconnaissance, fairway, wharf dredge and so on. Featuring a 17” large-size screen, industrial computer platform, and preinstalled marine surveying software, HD-MAX is designed for efficient, high-speed sounding performance. The integrated HD-Max Sounder software provides an excellent solution for marine surveying and mapping.

Detail advantage functions:

Friendly design
Multiple shortcut buttons ensure convenient field operation
Supports multi-screen display with VGA
Adjustable screen display angle
Optimized sounding techonology
Advanced signal tracking gate technology
Sampling rate up to 30Hz
Optimized TVG curve delivers improved sounding performance
Upgrading data processing framework to adapt to a more complex terrain environment
Easy to record and reply analog signals and water depth information
Compatibility and development
Supports other devices such as GNSS receivers,attitude indicators,sound velocimeters and electric gyrocompasses and so on
Optional built-in beacon module with precision up to 0.5 meters
Industrial computer platform
17“large-size screen
16GB SSD
One-key reset function
(4)Water-proof,rugged and durable with high strength polyethylene plastic shell

Key features

1) Optimized sounding technology

2) Industrial high speed computer platform

3) 17″ large-size screen with adjustable display angle

4) Userfriendly surveying compatible with hypack and etc.

The Hi-Target iBoat series USV with robust hull design and protective ducted propellers provides an entirely new option for high-resolution shallow-water hydrographic survey.Installed with multiple sensors，iBoat series USV could be controlled remotely to execute planned tasks with the help of satellites positioning.

Key Features

1.Stable trimaran design with ducted propellers

2.Available for multiple sonar instrumentations

3.Video transmission and obtacle avoidance

4.Digital and simulative echo signals combined

Detail Advantage Functions

1 Hull module

1）Trimaran design shape with portable size

2）Kevlar＆carbon high-strength composite

3）Propellers with ducted design and protective shield

4）Remote video and obtacle avoidance

2 Sounding module

1）Professional HD-MAX sounding module range from 0.15~300m

2）Digital and simulative echo signals combined

3）Independent HiMAX software available for collecting,guiding and post-processing

3 Application

1）Underwater topographic survey

2）Underwater landscape survey

3）Hydrographic survey

4）Water quality monitoring
